iM2306 Storm Case

pelican-hard-gun-scope-protective-casepelican-im2306-storm-attachment-casepelican-storm-im2306-rifle-scope-caseim2306_blk_low_1.jpgim2306_open_blk_low_1.jpgSAMSUNG DIGITAL CAMERAim2306_blk_low_2.jpg
Save Up to 20%
$235.96 – $267.96

The iM2306 is a long, narrow Storm case, 16 cm wide inside.

  • Interior: 43.2 x 16 x 15.8 cm
  • Exterior: 46.2 x 21.3 x 17 cm
  • Depth: lid 5.1 cm, base 10.7 cm
  • Weight: 1.9 kg empty, 2.1 kg with foam

Insert: Choose

Price
$235.96 – $267.96

Delivery estimate

Choose your options above for a delivery estimate.

Will it fit? Check your gear before you buy.

Pack one item or a whole kit, then see it in 3D. Inside this case: 432 × 160 × 158 mm

Try Will It Fit

Features of the iM2306 Storm Case

The iM2306 is a long, narrow Storm case, 16 cm wide inside. Inside it is 43.2 x 16 x 15.8 cm.

  • Two Press & Pull latches that lock automatically and open with a light touch
  • Watertight, crushproof and dustproof, rated IP67
  • HPX resin shell
  • O-ring seal and Vortex pressure purge valve
  • Double-layered soft-grip handle
  • Two padlockable hasps
  • Available with foam or no foam
  • Rated from −29°C to 60°C
  • Made in the USA
  • Pelican limited lifetime warranty

Specifications

Certifications
IP67
Colour
Black
Lid Depth
5.1 cm2.00"
Bottom Depth
10.7 cm4.20"
Total Depth
15.7 cm6.2"
Body Material
Injection Molded HPX™ high performance resin
Padlock Hole Diameter
8 mm5/16"
Latch Material
Valox - Polybutylene Terephthalate (PBT)
Latch Alt Material
Xenoy - Polyester/Polycarbonate blend
O-Ring Material
EPDM
Pins Material
Stainless Steel
Pins Alt Material
Aluminum
Foam Material
1.3/1.35 polyester
Purge Body Material
Valox - Polybutylene Terephthalate (PBT)
Purge Body Alt Material
Xenoy - Polyester/Polycarbonate blend
Purge Vent Material
Gore-Tex Membrane
Minimum Temperature
-29°C-20°F
Maximum Temperature
60°C140°F
Warranty
Limited Lifetime
